Power supply: adapter(input AC100-240V,50Hz/60Hz,
                     output DC9V-12V,＞300 MAX)
Power consumption: 4W
Monitor: 4 Digital LED display figures
DMX channels: 192CH
DMX output interface: 1×3P-XLR
Control mode: sound activate,auto,manual
Working environment: up to 40°C
Protection rate: IP20
Cover: A3
Dimension size: 480×130×65mm
Packing size: 560×180×100mm
                   580×385×535mm(10pcs/ctn)
N.W: 1.7kg      20.5kg(10pcs/ctn)
G.W: 2.1kg      21.6kg(10pcs/ctn)
Features: 30 banks of memory up to 240 scenes, 6 programmable chase memories.
total 192 DMX channels,controls 12 DMX Lights.16 channels for each light.
There are 30 BANKS, each with 8 programmable SCENES
8 adjustable potentiometers to adjust output size
Built-in MIC head for sound triggering
In the automatic trigger state, the automatic trigger time is determined
by the TAP SYNC button or the SPEED potentiometer.
With a MIDI interface, it can be controlled with MIDI signals at any time.
4-digit digital display.
The first digital tube displays CHASES and the second digital tube displays SCENES.
The third and fourth digit tubes display BANKS.
The second three or four digits display the number of steps or 0-255 or TIME.
The 1BLACKOUT function can be controlled remotely by manual or MIDI.
CHASES programming and CHASES run functions can be controlled manually or by MIDI remote control.
The output delay function uses the FADE TIME potentiometer to adjust the delay time.
DMX output polarity selection.
