LWM-1604 professional wireless microphone

0,000 TND

LWM-1604 professional wireless microphone

Receiver:
• Plastic construction;
• Plastic front panel;

•Frequency range 181.15Mhz

 Frequency range 197.60Mhz
• Digital pilot function;
• Single LCD display.
Transmitter:
• Plastic handheld microphone;
• Two AA batteries provide up to 6 hours of continuous use;
50 meters (170 feet) operating range (line of sight).
Quantité

SYSTEM

Audio Frequency Response：80~1200Hz

Dynamic Range：≥90dB

System Distortion：≤0.5%

SIGNAL-TO-NOISE RATIO：≥90dB

OPERATING RANGE：Appr.60M

OPERATING TEMPERATURE RANGE：-10℃~55℃

CARRIER FREQUENCY RANGE：180~270MHz

RECEIVER

Sensitivity(S/N=30dB):＞2mV

Image Rejection：≥50dB

De-Emphasis：50μs

Audio Output Level：600Ω±10%

Audio Output Level：0~0.5V

Power Supply：AC110V/220V

Current Consumption：5.5W

TRANSMITTER

Frequency Stability：±0.005%

RF Output Power：≤10mW

Spurious Rejection：＞50dB

Modulation Mode：FM

Maximum Deviation Range：±25KHz

Microphone Mode：Dynamic

Pre-Emphasis：50μs

Power Supply：9V Batt./AA1.5V×2

Current Consumption：≤35mA

LWM-1604
